Brand: MAHLE
Product Code: 0304000-1-10
Short descriptio
Piston VW POLO Variant III (6V5), Touring, 04.1997 - 09.2001 MAHLE 030 40 00 FITS THE FOLLOWING MODELS: SDI 1.9 (1997-2001) Diesel 47Kw/64Hp, AEYTDI 1.9 (1997-2001) Diesel 66Kw/90Hp, AGR, AHU, ALE, ALHTDI 1.9 (1998-2001... Read more...
96,77€
- Availability: In Stock
Piston VW POLO Variant III (6V5), Touring, 04.1997 - 09.2001 MAHLE 030 40 00
FITS THE FOLLOWING MODELS: SDI 1.9 (1997-2001) Diesel 47Kw/64Hp, AEY
TDI 1.9 (1997-2001) Diesel 66Kw/90Hp, AGR, AHU, ALE, ALH
TDI 1.9 (1998-2001) Diesel 81Kw/110Hp, AFN, ASV
Technical specifications: Mounting part: At cylinder 1
Mounting part: At cylinder 2
Length: 71.8
Piston bore: 79.51
Surface: coated (with a protective layer)
Machined: with relief/cutout for oil nozzle
Bolt-?: 26
Number of components: 1. R 1.75 Cr P
Number of components: 2. M2.0 IFU Cr P
Number of components: 3. DSF 3.0 Cr
Production number: 79 L 46< br> For cylinder: 1/2
Compression height: 45.8
Pot diameter: 37.9
Bolt length: 66
Pot depth 1: 17.65
Wall height: 9.1
Valve seat depth 1: 1.1
OE CODES: 4009026524909 ; ; 028107065BC; 038107065K; 038107065DC; 038107065AA001 ; 038107065H; 028107065AB; 028107065AL; 028107065H; 028107065AJ; 028107065K; 028107065DC; 028107065BT; 028107101AJ; 28107065H; 028107065BS; 028107065K; 028107101AJ; 028107065BS; 028107065AL; 028107065DC; 028107065H; 28107065H; 028107065BT; 038107065AA001 ; 038107065K; 028107065BC; 028107065AB; 038107065H; 028107065AJ; 038107065DC; 028107065BS; 028107065AB; 028107065BC; 028107065DC; 028107065AJ; 038107065K; 038107065H; 038107065AA001 ; 28107065H; 028107065K; 028107065AL; 038107065DC; 028107065BT; 028107101AJ; 028107065H
